Used Pfaudler 1 gallon T316L stainless steel reactor. Internal rated 200 psi / FV @ 500 degrees F. Jacket rated 150 psi @ 500 degrees F. Jacket side wall and bottom head. Gast Hydraulic drive model 4AM-NRV-22B with agitator. SN E382-1415. NB 42153 Built 1983.
Item 11275-001

Stainless Steel Reactors 1-99 Gallon
Used approximately 2 Gallon Chemineer autoclave/reactor. Internal rated 150 psi / FV @ 500 degrees F. Jacket rated 150 psi @ 500 degrees F. With Chemineer drive 3/4 hp motor 3 phase 60 cycle 208 220-440 volt 1140 rpm and agitator. Drive model 2-J-150-DFTN. Mounted on stand. Built 1985. Serial number 19152-B1. National board number 373.
Item 11275-003
Used approximately 2 Gallon Chemineer autoclave/reactor. Internal rated 150 psi / FV @ 500 degrees F. Jacket rated 150 psi @ 500 degrees F. With Chemineer drive 3/4 hp motor 3 phase 60 cycle 208 220-440 volt 1140 rpm and agitator. Mounted on stand. SN 191520-B2. NB 374.
Item 11275-002
Used Hopps Inc approximately 2 gallon stainless steel reactor system. reactor approximately 10"" diameter x 12"" high. Rated 150 psi @ 302 degrees f. internal. Jacket rated 150 psi at 302 degrees f. Agitator is belt driven by 1/2 hp drive. Skid mounted on steel base with Chromolox 4500 watt 240 volt electric hot oil heater system for jacket with pump and piping. Reactor system also includes controls and a chart recorder, and a shell and tube condenser.
Item 10896-002
Used Buchiglasuster stainless steel pilot reactor. 16.5 Liter capacity. Stainless steel contacts. 3 bar internal @ 700 degrees C. Electric jacket. SN 3874. Built 2004. Mounted in stand with vertical agitator and motor .55 kw 50 cycle. Spiral gate type agitator. Electric jacket. Tilt discharge. Rachet lift for top head.

Item 12113-004
Used 30 Gallon Hastelloy C-276 Reactor. Built by Pfaudler. Internal rated 150 psi @ 450°F. Jacket rated 115 psi @ 350°F. Clamped dished top. Dished bottom. Center mounted drive, agitator. Year: 1993. National Board #2640. Serial #: 2-9538

Item 11967-001
Used approximately 50 gallon working; 66 gallon total volume, T316L stainless steel reactor. Internal designed for Vacuum and rated for 50 psi @ 400 degrees F Min Design Metal Temp -20 degrees F. Jacket rated 100 psig @ 400 degrees F. Min Design Metal Temp -20 degrees F. 30" head dish radius. Shell 16 gauge. Serial No 6091-3. Year built 1993. 1/3 hp Ultramix Vektor Lightning top mounted mixer. Four legs.

Item 12084-001
Used 50 gallon Pfaudler reactor. Hastelloy C22 construction. 30" diameter X 18" straight side. Internal rated 100 psi/FV @ 480 degrees F. Jacket rated 90 psi @ 480 degrees F. 2.5 DTW Pfaudler drive vari speed with mechanical seal and lubricator 50-175 rpm.

Item 12074-001
